Limited 2024 Availability
220F
Photos may show optional equipment.
2024
220F
w/ 115 ELPT Pro XS FourStroke Command Thrust Mercury®
Price Excludes Optional Trailer
| View Price w/ Prep & Freight: | Select Dealer |
|
NO HAGGLE NO HASSLE® National Price
|
$43645
USD
|
Ideally appointed for casting and cruising
The Ranger® Reata® 220F blends the best qualities of a purpose-built leisure craft with a multitude of fishing-savvy touches. A 7-foot, 6-inch rod box with organizer graces the starboard side while fore and aft livewells keep bait – or your catch – close at hand. In between all this angling goodness is a plush lounge with a pair of rear-facing seats and a captain’s chair with self-leveling arms behind a fiberglass console with a full array of gauges. When it comes to setting the hook or settling down, the 220F is ideally appointed for casting or cruising.
Key Features
- PowerPod™ performance-enhancing motor extension for stronger and quieter operation
- Adjustable, swiveling & reclining helm chair with self-leveling arms & storage pouch
- 7’ 6” starboard lockable storage rod box with organizer
- Port bow 12-gallon timed, aerated livewell with rod and drink holders
Specifications
| Length | 7.37 m | 24' 2'' |
| Deck Length | 6.73 m | 22' 1'' |
| Deck Width | 2.59 m | 102'' |
| Max. Recommended HP | 150 HP | |
| Fuel Capacity | 121.12 L | 32 gal. |
| Pontoon Log Length | 6.78 m | 22' 3'' |
| Pontoon Log Diameter | 60.96 cm | 24'' |
| Pontoon Log Material | 0.080 5052 marine alloy | |
| Max. Person Capacity | 10 persons | |
| Max. Person Weight | 629.59 kg | 1388 lbs. |
| Max. Persons/Motor/Gear Weight | 929.86 kg | 2050 lbs. |
| Interior Depth | 60.96 cm | 24'' |
| Average Dry Weight | 1052.33 kg | 2320 lbs. |
| Average Package Weight | 1883.77 kg | 4153 lbs. |
| Package Height | 2.79 m | 9' 2'' |
| Package Width | 2.59 m | 8' 6'' |
| Towing Length | 9.86 m | 32' 4'' |
| Storage Length | 9.86 m | 32' 4'' |
Motor Options
| AVAILABLE MOTOR | |||||
|---|---|---|---|---|---|
| Mercury® | |||||
| 115 ELPT Pro XS FourStroke Command Thrust |
$43645 USD
|
Select Dealer | |||
| 150 L FourStroke |
$45995 USD
|
Select Dealer | |||
Standard Features
Craftsmanship
- ABYC® approved
- 24" (60.96 cm) diameter, .080 pontoon logs w/ individual chambers & internal supports
- 3/4" (1.91 cm) pressure-treated deck w/ every panel mechanically fastened to Z-bars
- All-aluminum, box beam transom
- Full-width extruded Z-bar deck support hidden fastener system
- Heavy-duty reinforced deck trim
- Heavy-duty, 1-piece extruded M-bracket deck support throughout
- Fire extinguisher & horn
- Multi-density furniture foam for maximum comfort
- Premium marine upholstery
- Stainless steel & coated carbon steel fasteners
- Ranger® 10-Year Lifetime Limited Structural Warranty
Electrical
- 500 GPH (1,893 LPH) aerator pump
- LED navigation lights
- LED navigation lights & built-in docking lights
- LED courtesy lighting throughout
- Motor kill switch w/ lanyard
- Phone management system w/ power outlets
- Sealed wiring connectors
- Wiring encased in conduit to prevent chafing
- Conveniently located 12V & USB outlets
Exterior
- NEW - Updated, modern graphics
- .032"-thick high-sheen fence panels
- 1-1/4" (3.2 cm) railing w/ mooring cover mounting track
- Available colors: charcoal metallic, black metallic, Ranger blue, pearl white, or matador red
- 4 Fold-down stainless steel cleats
- 4-step, fold-down, telescoping stainless steel boarding ladder w/ two tall handrails
- Aft boarding platform
- Bold exterior styling combining dimensional chrome graphics & externally-mounted anodized railings
- Elevated fencing for better drainage & ventilation
- Front porch area
- Noise-dampening fence insulation
- Port wheelchair-accessible gate
- Stylish deck trim w/ rub rail & highly polished aft corner castings
- Snapless, trailerable mooring cover w/ removable bow extension for full coverage at home, in the slip or on the road
Fishing
- 2 fore deluxe adjustable, swiveling & reclining fishing chairs w/ self-leveling arms & storage pouch & 2 aft fold-down, swiveling fishing chairs
- 7' 6" (2.29 m) starboard lockable rod box w/ organizer
- Port bow 12-gal. (45.42 L) timed aerated livewell & starboard bow battery compartment, both w/ rod & drink holders
- Aft 15-gal. (56.78 L) timed aerated livewell
- Aft fishing station w/ tool & rod holders & battery storage
- Pre-wired for easy installation of optional trolling motor and trolling motor front gate
Helm
- NEW - Ranger® RIDE System (Ranger Intelligent Display Engine) touch screen digital dash and 12-button switch panel
- Adjustable, swiveling & reclining helm chair w/ self-leveling arms & storage pouch
- Built-in footrest
- Recessed storage area
- Enclosed in-console cooler compartment w/ door-mounted molded storage
- Ergonomically-located throttle & steering wheel
- Tilt steering wheel
- Fire extinguisher
- Horn
- NEW - Wet Sounds® stereo w/Bluetooth & 2 upholstery speakers
- Molded shroud w/ soft-touch finish
- Automotive-style fuse panel
Interior
- NEW - Luxury woven cushioned floor
- NEW - 10' (3.05 m) Dowco® EasyLift™ Bimini top w/LED courtesy lights, storage pockets & protective boot
- Extra deep rain channels on all molded couch bases for drier storage
- Stowable table w/ molded-in drink holders
- Midship L-lounge w/ roto-molded, drained storage
- Aft bench-style lounge w/ roto-molded livewell & storage
Exterior
- Powder-coated pontoon logs
- 4:2 rotary steering w/ tilt
- Factory-rigged Mercury® outboard motors
- Performance-enhancing extended motor pod
- Factory-matched propeller
Options
Gallery
Photos may show optional equipment.
